Power Hacksaw Machines.
Ajax Power Hacksaw Machines — Compact, Precise, and Reliable Priced from £ 5,950.00
The Ajax series of power hacksaws is engineered to meet the demand for a compact, efficient cutting solution. Designed for precise, rapid, and cost-effective performance, these machines are ideal for workshops and industrial environments where reliability and ease of use are paramount.
Equipped with intuitive, user-friendly controls, Ajax hacksaws deliver consistent results with minimal operator training. Their robust design and proven performance make them a leading choice in the market today.
Specifications
| Model | AJPH250 Mk2 | AJPH320 Mk2 | AJPH400 Mk2 | AJPH500 Mk2 |
| Round Cutting Capacity at 90 Degrees (mm) | 250 Dia | 320 Dia | 400 Dia | 500 Dia |
| Square Cutting Capacity at 90 Degrees (mm) | 220 x 220 | 290 x 290 | 330 x 330 | 400 x 400 |
| Round Cutting Capacity at 45 Degrees (mm) | 80 | 130 | 150 | 160 |
| Blade size (mm) | 350 x 32 x 1.6 | 450 x 32 x 1.6 | 550 x 45 x 2 | 650 x 50 x 2 |
| Motor Power (kw) | 2.4 | 3 | 3 | 3 |
| Cutting Speeds (SPM) | (6) 39 – 126 | (3) 39 – 70 | (3) 39 – 70 | (3) 39 – 70 |
| Feed Range | Inf Variable | Inf Variable | Inf Variable | Inf Variable |
| Overall Size (cm) | 200 x 95 x 130 | 224 x 102 x 160 | 244 x 102 x 160 | 244 x 119 x176 |
| Machine Weight (Kg) | 600 | 1,100 | 1,200 | 1,450 |
Ajax Power Hacksaw Machines
General Construction.
Durable Construction and Efficient Coolant Management
The base, bow, and primary components of our machines are constructed from high-quality cast iron, ensuring long-lasting durability and vibration resistance during operation.
The worktable is thoughtfully designed to allow for the efficient flow of coolant over the workpiece and its smooth return to the integrated coolant tank. This enhances cutting performance, improves tool life, and keeps the workspace clean and safe.
Vice.
The vice is made from high-quality cast iron and is easily adjustable, allowing the operator to switch between different sizes of material in a matter of seconds.
Adjustable Down Feed & Automatic Cut-Off
The down feed of the saw frame is easily adjustable via a simple control knob, allowing operators to set the feed rate from minimum to maximum as needed. This ensures precise and effortless cutting of both thin-walled steel tubes and solid bars, with consistent control maintained throughout the operation.
For added convenience and safety, all machines come equipped with an automatic cut-off feature, which stops the machine at the end of the cutting stroke.
Electrical Control System
Our machines feature a robust control circuit equipped with a no-voltage overload release and thermal relays, ensuring safety and protection during operation.
They are supplied as standard in 415V, 3-phase, 50Hz, with alternative voltages available upon request (3-phase only), allowing flexibility to meet your specific electrical requirements.
